LNS Alpha ST 320 - Pneumatic System

CHAPTER 5: PNEUMATICS
ALPHA ST 320
5-3
1.3 Pneumatic System
Designation Description Designation Description
A
Guiding channel open / close
cylinder
YV2A Guiding channel open solenoid
B Vise cylinder YV2B Guiding channel closed solenoid
C Measuring device cylinder YV3 Vise jaw closed solenoid
SP1 Air pressure switch YV4 Spare
YV0 Measuring device solenoid YV5 Air blast solenoid
YV1 Front Rest
A
B
C
