Load Cell Systems TLB4 User Manual

- 7 -
TERMINALS LEGEND
1
OUTPUT No. 1
17
+LOAD CELLS 1 and 2 EXCITATION (+EX)
2
OUTPUT No. 2
18
-LOAD CELLS 1 and 2 EXCITATION (-EX)
LOAD CELLS SHIELD
3
OUTPUT No. 3
19
+LOAD CELL 2 SIGNAL
4
OUTPUT COMMON
20
-LOAD CELL 2 SIGNAL
5
INPUT No. 1 (+VDC min 5 V max 24 V)
21
+LOAD CELLS REF/SENSE
6
INPUT No. 2 (+VDC min 5 V max 24 V)
22
-LOAD CELLS REF/SENSE
7
INPUT COMMON (-VDC 0 V)
23
+LOAD CELL 3 SIGNAL
8
+SUPPLY (12/24 VDC)
24
-LOAD CELL 3 SIGNAL
9
-SUPPLY (12/24 VDC)
RS485: SHIELD, GND
25
+LOAD CELLS 3 and 4 EXCITATION (+EX)
10
+ANALOG OUTPUT 0÷20 or 4÷20 mA
(TLB4 only)
26
-LOAD CELLS 3 and 4 EXCITATION (-EX)
LOAD CELLS SHIELD
11
+ANALOG OUTPUT 0÷10 V
(TLB4 only)
27
+LOAD CELL 4 SIGNAL
12
-ANALOG OUTPUT COMMON
(TLB4 only)
28
-LOAD CELL 4 SIGNAL
15
+LOAD CELL 1 SIGNAL
29
RS485: +
16
-LOAD CELL 1 SIGNAL
30
RS485: -
