MAIN SPECIFICATIONS OF THE INSTRUMENT
Weight transmitter with 6-wire load cells inputs suitable for assembly on back panel fitted
Omega/DIN rail or on front panel using the included mounting kit. Dimensions: 26x115x120 mm.
Six-digit semialphanumeric display, 8 mm height, 7 segment. Four-key keyboard.
RS485 serial port for connection to: PC/PLC up to 32 instruments (max 99 with line repeaters)
by ASCII or ModBus R.T.U. protocol, remote display, printer. Optional: integrated Profibus DP,
DeviceNet, CANopen, Profinet IO, Ethernet/IP, Ethernet TCP/IP, Modbus TCP, RS232/
RS485, SERCOS III, PowerLink, CC-Link output.
TLB4 only: optoisolated 16 bit analog output (tension or current).
8 independent channels:automatic detection of connected load cells.
Digital equalization: load cell response uniformed via software.
Load distribution: indication of the weight percentage on each load cell.
Automatic diagnostics: load distribution check to detect any faults.
Events log: storage of the last 50 events: calibrations, zero-settings, errors, equalizations.
Alarm Relay: outputs can be set to switch in case of alarm.
