- 33 -
USE WITH W SERIES INSTRUMENTS
WARNING: the weight indicator must be properly configured before operating in
combination with the multi-channel weight transmitter (see section DATA DELETION
AND PROGRAM SELECTION in W serie instrument manual) and the approval status
set on both instruments must be the same.
When the TLB4 is used in combination with a W serie instrument, the load cells are connected to the
multi-channel weight transmitter, which transmits the weight to the indicator; all the operations of
calibration, zeroing, equalization and channel selection can be performed remotely through the
indicator.
CONNECTION TO THE WEIGHT INDICATOR
Connection via RS485 port.
Weight indicator configuration
Configure, on the serial port used, the protocol with the following parameters:
= = =
TLB4 multi-channel weight transmitter configuration
Configure, on the serial port used, the MODBUS protocol with the following parameters:
= = =
