- 42 -
PROGRAM SELECTION: confirm and use the arrow keys to select the desired program:
: basic program, setpoint management only.
: to be used when the loaded weighing system correspond to not loaded cells and vice versa
(product increases while weight on load cells actually decreases).
: weight remote display program with setpoint.
After confirming the choice of the program (except and ), the user must choose its
approval status among the following possible choices:
: not approved program;
: approved program, single interval (Dir. 2014/31/EU, art. 1)*;
: approved program, multi-interval (Dir. 2014/31/EU, art. 1)*;
*) Contact technical assistance to request the proper manual and the correct procedures for
approval, indicating mandatory hardware code and serial number (see section
INSTRUMENT COMMISSIONING).
When the TLB4 is used in combination with a W serie instrument, the approval status set
on both devices must be the same.
By confirming, the instrument is restored to default and data is erased.
If you do not have a specific manual for the newly set program, you can request it
to technical assistance.
KEYPAD OR DISPLAY LOCKING
Press immediately followed by and hold them down for about 5 seconds (this operation is
also possible via the MODBUS and ASCII protocols):
- : no lock.
- : keypad lock: if active, when a key is pressed the message is displayed for 3
seconds.
- : keypad and display lock: if active, the keypad is locked and the display shows the
instrument model (weight is not displayed); by pressing a key the display shows for 3
seconds.
Load Cell Systems reserves the right to change specifications without notice. ©2019
