Load Cell Systems TLB4 User Manual

- 39 -
LOAD DISTRIBUTION PRINT
Current distribution: press the key from the  menu.
Current and stored distribution: from the  and  menus, keep pressed the key for
more than 3 seconds while the weight is displayed.
CURRENT DISTRIBUTION
-----------------------
TLB4 BASE Addr:01
CURRENT (STATUS)
GROSS 2014 kg
CH1: 23.5 %
CH2: 24.1 %
CH3: ERR (load cell connected but in error)
CH4: OFF (load cell not connected)
CURRENT AND STORED DISTRIBUTION
-----------------------
TLB4 BASE Addr:01
STORED (MEMRIP)
GROSS 2014 kg
CH1: 23.5 %
CH2: 24.1 %
CH3: ERR (load cell connected but in error)
CH4: OFF (load cell not connected)
GROSS OLD 2050 kg
CH1: 25.5 %
CH2: 22.1 %
CH3: ERR (load cell connected but in error)
CH4: OFF (load cell not connected)
