Reference 55-85
User manual
29

Initial installation
Setting options for DVB-S reception (continued):
After you have made the previous settings, you should
receive picture and sound of the selected satellites
(only possible for Astra1 and HOTBIRD).
 Proceed to next step.
 Select and adapt settings.
If several satellites are received, the following settings
must be made for every satellite. The type of settings
available may differ depending on the selected satellite
or network.
Scrambled
stations
You can state whether coded stations are to be
searched for in the search/update.
Select yes to save all found scrambled stations.
However, these stations can only be received in
connection with a CA module and the appropriate
Smart Card.
Handling of the CA module is described in chapter
System settings, section Extras – CA module.
Search
method
If you select Frequency search here, a search is
performed for all receivable stations. With Network
search, from all receivable networks all the stations
are searched which are supplied by these networks.
Depending on the selected network, this step
might possibly be skipped.
Symbol rate The symbol rate is specified by the satellite provider
and normally does not need to be changed.
Accept
Logical
Channel
Number
In various countries, digital stations (DVB-S) are
transmitted with a preset channel number per
station, known as Logical Channel Numbers (LCN).
If you select yes here, these default channel slots
will be used and the channels of the preferred signal
source will be sorted as per LCN. The stations in the
station list can no longer be shifted.
 Proceed to next step.
Proceed to section Setting options for all types of
reception.
Test reception
You should now receive a picture and sound from the following satellite:
Astra1 19,2°E C/N Level
Otherwise, please adjust your antenna. If it is already correctly adjusted, please continue all
the same, without receiving picture or sound for the moment.
Back with Proceed with
Settings
Please specify whether you want to search for scrambled stations too.
Note: Scrambled stations can only be received with an integrated CA module and
additional card.
Scrambled stations
Search method
Symbol rate
Accept Logical Channel Number
DVB-S settings (ASTRA1 19,2°E)
Back with Proceed with
no
yes
Network search
Frequency search
22000
no
yes
