21Carbide Cutter OM
Maintenance
Grease Points Location (Cont'd)
Use a #2 general purpose lithium based grease unless
noted otherwise.
NOTE: Replace any broken or missing grease fittings.
Be sure to clean fittings before greasing.
8
NOTE: Lubricate the grease point every “X” hours
indicated on the decal adjacent to the grease
point.
Numbers below after “Location” correspond to grease
point locations on opposite page.
See “Carbide Cutter Identification” on page 8 for
component location and identification.
• Rotor Bearings Grease Fittings
Location:
(1) Left side: Located at the left side of the
carbide cutter, at the top of the bearing guard
(2) Right side: Located at the base of the
front push bar arm. Lubricate the fitting
through the opening of the frame, (bottom
grease fitting)
.
NOTE: Rotor bearings cannot be damaged by over-
greasing. Grease fittings until a small amount of
grease is purged from the bearing.
Interval: Daily or every 8 hours of operation.
• Belt Tensioner Grease Fitting
Location: (3) - Located at the base of the front push bar
arm, right side. Lubricate the fitting through
the opening of the frame, (top grease fitting).
NOTE: Remove the belt cover when lubricating the fitting.
Visually inspect the idler pulley components
while lubricating. Do Not over lubricate the idler
tensioner shaft.
NOTE: Over lubricating may be transferred to the belt,
causing the belt to slip, resulting in loss of rotor
RPM speed and loss of power to the rotor.
Interval: Every 50 hours of operation.
Overhung Load Adapter
NOTE: If replacing bearings or seals in the overhung
load adapter, be certain to refill with 6 oz. of
hydraulic fluid after reassembly.
