LOFTNESS 51CCH - Rear Cutter Bar 51 (N20282), 61 (N20281), 71 (N21908)

54 Carbide Cutter OM
Rear Cutter Bar 51" (N20282), 61" (N20281), 71" (N21908)
# QTY. PART # DESCRIPTION
1
1 N20264 PLATE, 51" CARBIDE CUTTER
1 N20238 PLATE, 61" CARBIDE CUTTER
1 N21909 PLATE, 71" CARBIDE CUTTER
2
14 4452 NUT, 5/8" - 18UNF STANDARD FINE THREAD (51")
16 4452 NUT, 5/8" - 18UNF STANDARD FINE THREAD (61")
18 4452 NUT, 5/8" - 18UNF STANDARD FINE THREAD (71")
3
21 N16473 WASHER, 5/8" NORDLOCK (51")
24 N16473 WASHER, 5/8" NORDLOCK (61")
27 N16473 WASHER, 5/8" NORDLOCK (71")
4
7 N20247 MOUNT, CARBIDE REAR CUTTER ANGLE (51")
8 N20247 MOUNT, CARBIDE REAR CUTTER ANGLE (61")
9 N20247 MOUNT, CARBIDE REAR CUTTER ANGLE (71")
5
7 4069 WASHER, FLAT 5/8" (51")
8 4069 WASHER, FLAT 5/8" (61")
9 4069 WASHER, FLAT 5/8" (71")
6
7 4042 BOLT, 5/8" x 2" FINE THRD. GR. 8 (51")
8 4042 BOLT, 5/8" x 2" FINE THRD. GR. 8 (61")
9 4042 BOLT, 5/8" x 2" FINE THRD. GR. 8 (71")
1
2
3
4
5
3
6
Parts Identification
