59Carbide Cutter OM
Appendix
DESCRIPTION CARBIDE CUTTER
Cutting Width 51 in. (129.5 cm)
61 in. (154.9 cm)
71 in. (180.3 cm)
Operating Capacity 6 in. (15.2 cm) Continuous
10 in. (25.4 cm) Intermittent
Capacity Monitor Pressure Gauge
Motor Fixed Piston (#5 & #6 Hyd Systems)
Variable Displacement, (#9 & #10 Hyd Systems)
Rotor Bearing 2.1875 in. Piloted Double Taper
Rotor Tip Diameter 17 in. (43.2 cm)
Sheaves Taperlock
Belt Four Band 5VX Type
Belt Tightener Spring Loaded Tensioner
Mount Universal Skid Type
Shear Bar Adjustable
Pusher Bar Adjustable Rigid Bar
Knives Double Carbide Teeth
Double Carbide Planer Teeth (Optional)
Quadco Planer Teeth, Sharpenable (Optional)
Skid Shoes Adjustable 1 in. (2.5 cm) - 3 in. (7.6 cm)
Deflector Steel Chain
Anti-Wrap Protection Bearing
Specifications
