36 Carbide Cutter OM
LP
1000 PSI
6000 PSI
Oil Flow Direction
“Forward”
HP
MAMB
HPG LPG
CB
CV
IN OUT
Parts Identification
Motor Assembly #530 Open (N28409)
1
2
TO MOTOR COVER
PRESSURE GAUGE
TO CASE DRAIN
3*
4
5
6
7
8
9
10
11
12
13
12
14
* Item 3 (N21669) parts breakdown.
3a**
3b***
3c***
3d**
Valve Open Loop CW (N21669) Schematic
** Use item 15 in parts list, part number N38181, for
seal kit for items 3a and 3d.
*** Use item 16 in parts list, part number N14170, for
seal kit for items 3b and 3c.
