LOFTNESS 51CCH - Belt Tensioner (N28018)

48 Carbide Cutter OM
Parts Identification
Belt Tensioner (N28018)
# QTY. PART # DESCRIPTION
1 1 4459 BOLT, 5/8" x 3" GRADE 8
2 1 N16473 WASHER, 5/8" NORDLOCK
3 1 N10508 PULLEY, IDLER BELT
4 Varies N28269 WASHER, HARDENED 5/8" x 1 - 3/4"
5 1 N28382 SLIDE, BELT TIGHT SQ ASSY
6 1 N24211 SPRING, BELT TIGHTENER
7 1 4250 NUT, STANDARD 1/2"
8 1 N28019 BASE, BELT TIGHT SQ SLIDE
9 1 N24596 ROD, THREADED 1/2" x 7.66" W / NUT
10 1 N28018 TENSIONER, BELT 4 BAND
1
2
3
4
5
8
9
6
7
10
