47Carbide Cutter OM
Parts Identiļ¬cation
Hydraulic Hose Assembly (N28471)
# QTY. PART # DESCRIPTION
1 2 N28273 HOSE, 1" X 126" HYD W/O SLEEVE -16MORB B.E.
2 2 N28108 ADAPTER, - 12MOR - 16FOR
3 2 N32001 PLUG, 1.00 X .3125
4 2 N15893 CAP, 3/4" ALUMINUM HOSE
5 1 N15895 CAP, 1/2 ALUMINUM HOSE
6 1 N32002 PLUG, 3/8 SCH 40 X .25
7 1 N28358 HOSE, 1/2" X 144"-8FJIC -8MORB
8 1 N28352 SLEEVE, HOSE 4.75 X 8'6"
8
1
1
2
3
4
4
3
2
5
6
7
