37Carbide Cutter OM
Motor Assembly #530 Open (N28409)
# QTY. PART # DESCRIPTION
1 1 N28893 ADAPTER, - 6FJIC - 6FP
2 1 N28907 ELBOW, 90DEG - 6MJIC - 4MOR
3 1 N21669 VALVE, OPEN LOOP CW
3a 1 N28100** RELIEF, LOW PRESSURE 1000PSI
3b 1 N28102*** VALVE, CHECK PILOT OPERATED
3c 1 N28103*** VALVE, COUNTERBALANCE
3d 1 N28099** RELIEF, HIGH PRESSURE 5000PSI
4 8 N21917 WASHER, HIGH COLLARLOCK 7/16"
5 8 N21915 BOLT, SHCS 7/16" x 2 - 1/4" GRADE 5
6 1 N20976 BLOCK, VALVE
7 8 N21914 BOLT, SHCS 3/8" x 2 - 1/2" GRADE 5
8 8 N21916 WASHER, HIGH COLLARLOCK 3/8"
9 1 N16173 ELBOW, 90 DEG - 8 MJC - 10 MOR
10 1 N20840 MOTOR, VOAC 60
11 4 N28502 BOLT, 1/2" x 1 - 1/2" 12 PT GRADE 8
12 8 N16472 WASHER, 1/2" NORDLOCK
13 1 N20901 ADAPTER, 900 SER LOAD 4.5 SHAFT
14 4 4013 BOLT, 1/2" x 1 - 1/2" GRADE 5
15 1 N38181 KIT, SEAL CART SUN RDFA-LCN
16 1 N14170 KIT, COUNTER BALANCE SEAL
Parts Identiļ¬cation
** Use item 15, part number N38181, for seal kit for valves N28099 and N28100.
*** Use item 16, part number N14170, for seal kit for valves N28102 and N28103.
