35Carbide Cutter OM
Parts Identification
Carbide Cutter Body Assembly (Cont'd)
# QTY. PART # DESCRIPTION
1 1 N19600 HOLDER, MANUAL
2 3 4340 BOLT, 1/4" x 3/4’ GRADE 5
3 6 4071 WASHER, 3/4" FLAT
4 6 4287 WASHER, 3/4" LOCK
5 2 4244 BOLT, 3/4" x 4 - 1/2" BOLT GR 5
6 2 N17007 GREASE - ZERK, 1/8 NPT
7 4 4472 ELBOW, 1/8" 90 DEG. STREET
8 4 4029 BOLT, 3/4" x 6" GRADE 5
9 2 4304 - 10 BULKHEAD. FITTING - GREASE HOSE
10 2 4304 HOSE, 15" GREASE W / FITTINGS
11 1 N20572 STAND, CARBIDE SHIPPING RIGHT
12 12 4070 WASHER, LOCK 5/8"
13 12 4055 NUT, LOCK 5/8" TOP
14 1 4471 ELBOW, 1/8" 45 DEG. STREET
To Next Page
