29Carbide Cutter OM
Carbide Cutter Drive Assembly
# QTY. PART # DESCRIPTION
1 1 4054 NUT, LOCK 1/2" TOP
2 1 N28333 HOLDER, HOSE WELDMENT
3 1 4154 BOLT, 1/2" X 3 - 1/2" GRADE 5
4 11 4005 BOLT, 3/8" x 1 - 1/4" GRADE 5
5 11 4065 WASHER, 3/8" LOCK
6 11 4064 WASHER, FLAT 3/8"
7 4 N16472 WASHER, 1/2" NORDLOCK
8 4 4012 BOLT, 1/2" x 1-1/4" GRADE 5
9 1 N28471 KIT, HOSE CCH 1" x 126" & 144"
10
Not a
replacement
part.
1 CARBIDE, 51" CARBIDE W / STD CUTTERS
1 CARBIDE, 61" CARBIDE W / STD CUTTERS
1 CARBIDE, 71" CARBIDE W / STD CUTTERS
11
1 N28406 PLATE, CARBIDE 51" HOSE SHIELD
1 N28354 PLATE, CARBIDE 61" HOSE SHIELD
1 N28407 PLATE, CARBIDE 71" HOSE SHIELD
12 1 N15974 SHIELD, CARB MTR W / GAUGE
13
1 N28409 MOTOR ASSY, #530 OPEN
1 N28410 MOTOR ASSY, #630 CLOSED
1 N28472 MOTOR ASSY, #933 OPEN 15 BAR
14 1 N28018 TENSIONER, BELT 4 BAND
15
1 N20810 SHEAVE, 4/5V x 8.50 - 2517 (MODEL CODE “F”)
1 N20809 SHEAVE, 4/5V x 8.00 - 2517 (MODEL CODE “H”)
1 N20806 SHEAVE, 4/5V x 9.00 - 2517 (MODEL CODE “J”)
16 1 8126 BUSHING, 1 - 1/2" TAPERLOCK KEYED
17 1 7121 - 02 KEY, 3/8" x 1 - 3/4"
18 1 N28703 BELT, 4/5V x 63 GATES
19 1 N20004 SHIELD, CARBIDE BELT
20 6 N18360 BOLT, 1/2" x 1 - 1/4" SERATED FLANGE
21
1 N18974 SHEAVE, 4/5V x 9.75 - 3020 (MODEL CODE “F”)
1 N20811 SHEAVE, 4/5V x 10.30 - 3020 (MODEL CODE “H”)
1 N18974 SHEAVE, 4/5V x 9.75 - 3020 (MODEL CODE “J”)
22 1 7122 - 04 KEY, 1/2" x 2"
23 1 N18975 BUSHING, 2 - 3/16’ TPL 1/2" KEY 117121
Parts Identification
