Parts Identiļ¬cation
Carbide Cutter Body Assembly
# QTY. PART # DESCRIPTION
1 2 4244 BOLT, 3/4" x 4 - 1/2" GRADE 5
2
1 N21094 PUSHER, 51" CARBIDE
1 N20100 PUSHER, 61" CARBIDE
1 N20167 PUSHER, 71" CARBIDE
3 2 N19048 ARM, CARBIDE PUSHER MECHANICAL
4 4 4029 BOLT, 3/4" x 6" GRADE 5
5 6 4287 WASHER, 3/4" LOCK
6 6 4071 WASHER, 3/4" FLAT
7 1 N15989 SKID, CARBIDE RIGHT
8
Not a
replacement
part.
1 BODY, 51" CARBIDE
1 BODY, 61" CARBIDE
1 BODY, 71" CARBIDE
9
56 N15589 CHAIN, CARBIDE REAR 51"
66 N15589 CHAIN, CARBIDE REAR 61"
76 N15589 CHAIN, CARBIDE REAR 71"
10 2 4375 PIN, ROLL 3/16" x 1"
11
1 N20062 ROD, CARBIDE 51" CHAIN
1 N20102 ROD, CARBIDE 61" CHAIN
1 N20166 ROD, CARBIDE 71" CHAIN
12 1 4336 CLIP, HAIRPIN 1/8" x 2 - 1/4"
13 1 N15995 PIN, 3/4" x 5 - 3/4"
14 4 4155 WASHER, LOCK 1/2"
15 4 4012 BOLT, 1/2" x 1 - 1/4" GRADE 5
16 1 N20579 STAND, CARBIDE SHIPPING LEFT
17 1 N15987 SKID, CARBIDE LEFT
18 12 4055 NUT, LOCK 5/8" TOP
19 12 4070 WASHER, LOCK 5/8"
To Next Page
