LOFTNESS 51CCH - Page 43

33Carbide Cutter OM
Carbide Cutter Body Assembly (Cont'd)
Parts Identification
# QTY. PART # DESCRIPTION
1 2 N16417 BEARING, 2 - 3/16" PILOT ROLLER
2 2 N20059 MOUNT, CARBIDE ROTOR BEARING
3 2 N18929 ANTIWRAP, CARBIDE MACHINED 2 - PIECE
4
1 N20083 ROTOR, 51" CARBIDE WITH DOUBLE CUTTERS
1 N20077 ROTOR, 61" CARBIDE WITH DOUBLE CUTTERS
1 N20080 ROTOR, 71" CARBIDE WITH DOUBLE CUTTERS
5 1 N16445 BUSHING, 2 - 3/16" ID x 2 - 3/4" OD
6 1 4075 WASHER, 2 -5/8" OD BEARING RETAINER
7 1 4076 WASHER, 1/2" EXT CNTSK LOCK
8 1 N20012 GUARD, BEARING WELDED
9 2 4012 BOLT, 1/2" x 1 - 1/4" GRADE 5
10 2 4155 WASHER, LOCK 1/2"
11 2 4068 WASHER, 1/2" SAE FLAT
12 1 4468 SCREW, 1/2" x 20UNF x 1 1/4" FN TD FL HD CAP
13 1 4085 PIN, ROLL 3/16" x 3/4"
14 8 N20043 BOLT, 1/2" x 2 - 1/4" FN TD GR 8
15 8 N16472 WASHER, 1/2" NORDLOCK
16 10 4494 BOLT, 5/8" x 2 - 1/4" GRADE 8 FINE THREAD
17 10 N16473 WASHER, 5/8" NORDLOCK
