39Carbide Cutter OM
Motor Assembly #630 Closed (N28410)
Parts Identiļ¬cation
# QTY. PART # DESCRIPTION
1 1 N16066 ELBOW, - 6 MOR - 6FP / 90 DEG
2 1 N23026 VALVE, RELIEF CLOSED LOOP CW
2a 1 N28100** VALVE, RELIEF LOW PRESSURE 1000PSI
2b 1 N28101 VALVE, HOT OIL SHUTTLE
2c 1 N28098 VALVE, PURGE FLOW CONTROL
2d 1 N28099** VALVE, RELIEF HIGH PRESSURE 5000PSI
3 1 N20976 BLOCK, VALVE
4 8 N21917 WASHER, HIGH COLLARLOCK 7/16"
5 8 N21915 BOLT, SHCS 7/16" x 2 - 1/4" GRADE 5
6 8 N21914 BOLT, SHCS 3/8" x 2 - 1/2" GRADE 5
7 8 N21916 WASHER, HIGH COLLARLOCK 3/8"
8 1 N16166 HOSE, 3/8" x 24" - 6 FJIC - 8 MOR
9 1 N21992 ELBOW, 90 DEG - 6 MJIC - 10 MOR
10 1 N16173 ELBOW, 90 DEG - 8 MJC - 10 MOR
11 1 N20840 MOTOR, VOAC 60
12 4 N28502 BOLT, 1/2" x 1 - 1/2" 12 PT GRADE 8
13 8 N16472 WASHER, 1/2" NORDLOCK
14 1 N20901 ADAPTER, 900 SER LOAD 4.5 SHAFT
15 4 4013 BOLT, 1/2" x 1 - 1/2" GRADE 5
16 1 N38181 KIT, SEAL CART SUN RDFA-LCN
** Use item 16, part number N38181, for seal kit for valves N28099 and N28100.
To Next Page
