41Carbide Cutter OM
Parts Identiļ¬cation
# QTY. PART # DESCRIPTION
1 8 N28353 BOLT, SHCS 3/8" x 3 - 1/4"
2 8 N21916 WASHER, HIGH COLLARLOCK 3/8"
3 1 N28203 VALVE, RELIEF OPEN LOOP CW
3a 1 N28100** VALVE, RELIEF LOW PRESSURE 1000PSI
3b 1 N28102*** VALVE, CHECK PILOT OPERATED
3c 1 N28103*** VALVE, COUNTERBALANCE
3d 1 N28099** VALVE, RELIEF HIGH PRESSURE 5000PSI
4 1 N28893 ADAPTER, - 6FJIC - 6FP
5 1 N28907 ELBOW, 90DEG - 6MJIC -4MOR
6 1 N29731 ADAPTER, - 8MJIC - 12MOR
7 1 N19068 ELBOW, 90 DEG - 6MJIC - 8FJIC
8 2 N16125 U - BOLT, 5/16" x 2 - 1/2" x 3 - 1/2"
9 1 N16074 ACCUMULATOR, 500 PSI / 10 C.I.
10 1 N16128 MOUNT, ACCUMULATOR W / STOPS
11 4 4460 WASHER, FLAT 1/4"
12 4 4228 WASHER, 5/16" LOCK
13 4 4237 NUT, 5/16" STANDARD
14 2 4195 BOLT, 3/8" x 1" GRADE 5
15 2 4065 WASHER, 3/8" LOCK
16 1 N16166 HOSE, 3/8" x 24" - 6FJIC - 8MOR
17 1 N24827 ELBOW, 90 DEG - 8FJIC - 8MJIC
18 1 N12444 ADAPTER, - 8MJIC - 10MOR
19 4 N28502 BOLT, 1/2" x 1 -1/2" 12 PT GRADE 8
20 8 N16472 WASHER, 1/2" NORDLOCK
21 1 N28205 MOTOR, VARIABLE 15 BAR
22 1 N20901 ADAPTER, 900 SER LOAD 4.5 SHAFT
23 4 4013 BOLT, 1/2" x 1 - 1/2" GRADE 5
24 1 N38181 KIT, SEAL CART SUN RDFA-LCN
25 1 N14170 KIT, COUNTER BALANCE SEAL
Motor Assembly #933 Open 15 Bar (N28472)
** Use item 24, part number N38181, for seal kit for valves N28099 and N28100.
*** Use item 25, part number N14170, for seal kit for valves N28102 and N28103.
To Next Page
