43Carbide Cutter OM
Parts Identiļ¬cation
Motor Assembly #1033 Closed 15 Bar (N28500)
# QTY. PART # DESCRIPTION
1 8 N28353 BOLT, SHCS 3/8" X 3-1/4"
2 8 N21916 WASHER, HIGH COLLARLOCK 3/8"
3 1 N28636 VALVE, RELIEF CLOSED LOOP CW
3a 2 N28100** VALVE, RELIEF LOW PRESSURE 1000 PSI
3b 1 N28098 VALVE, PURGE FLOW CONTROL
3c 1 N28101 VALVE, HOT OIL SHUTTLE
3d 1 N28099** VALVE, RELIEF HIGH PRESSURE 5000 PSI
4 1 N29731 ADAPTER, 8MJC - 12MOR
5 1 N19068 ELBOW, 90 DEG - 6MJIC - 8FJIC
6 1 N16066 ELBOW, 6 MOR -6FP/90 DEG
7 2 N16166 HOSE, 3/8X24" (6FJX-8MOR)
8 1 N21992 ELBOW, 90 DEG - 6 MJIC - 10 MOR
9 2 N16125 U-BOLT, 5/16 X 2-1/2 X 3-1/2
10 1 N16074 ACCUMULATOR, 500PSI/10 C.I.
11 1 N16128 MOUNT, ACCUMULATOR W/STOPS
12 4 4460 WASHER, FLAT 1/4"
13 4 4228 WASHER, 5/16" LOCK
14 4 4237 NUT, 5/16" STANDARD
15 2 4195 BOLT, 3/8" X 1" GRADE 5
16 2 4065 WASHER, 3/8 LOCK
17 1 N20901 ADAPTER, 900 SER LOAD 4.5 SHAFT
18 4 4013 BOLT, 1/2" X 1-1/2" GRADE 5
19 8 N16472 WASHER, 1/2 NORDLOCK
20 1 N28205 MOTOR, VARIABLE 15BAR
21 4 N28502 BOLT, 1/2" X 1-1/2" 12PT GRD 8
22 1 N12444 ADAPTER, 8MJIC - 10MOR
23 1 N24827 ELBOW, 90 DEG - 8FJC - 8MJC
24 1 N38181 KIT, SEAL CART SUN RDFA-LCN
** Use item 24, part number N38181, for seal kit for valves N28099 and N28100.
