CONNECTIONS
Note:
When connecting a DVD player to thetelevision,the picture resolutionis dependent
upontheresolutionofboththeDVDplayerandtheTV.Forbestresults,selectthehighest
resolutionoftheDVDuptotheTVmaximumof1080i.
CONNECTING A HIGH-DEFINITION (HD) SOURCE (YUV)
High-Denition(HD)DeviceswithcomponentvideooutputmustbeconnectedtotheYUV
input.
Connectthecomponentvideocableandaudiocable(notincluded)asshown.
MakesureyouconnecttheYUVScartadaptortothisunit,thenconnectcomponentvideo
cableandaudiocablefromtheotherequipment(COMPONENT VIDEO OUT and AUDIO
OUT)tothisunit(SCARTandAUDIO IN).
Tooperatetheconnecteddeviceandplaythesource,rstpresstheFUNCTIONbutton
toselecttheYUV/SCARTmode.
* Mayrequire a subscription for
receiving HD channels. Check
with your cable/satellite service
providerfordetails.
ToAUDIOIN
jacks
ToAUDIO
OUTjacks
ToCOMPONENT
VIDEOOUTjacks
ToSCART
jacks
CONNECTING A PC
Connectthe15-pinD-SUBPC/VGAconnectorfrom
yourcomputertothe15-pinD-SUBPC/VGAinput
onthisunitusingamonitorcableandstereoaudio
cable(notincluded)asshown.
Makesureyouconnectthecablefromthecomputer
(PC ConnectorandAUDIO - PC OUT)tothisunit
(MONITOR/VGA andAUDIO - PC IN).Pressthe
FUNCTIONbuttontoselectPCmode.
ToAUDIOjack(PC OUT)
ToPC connector
StereoAudio
Cable
15PinD-SUB
connector
PREPARATION
CONNECTIONS USING THE FEATURES SPECIFICATIONTROUBLESHOOTING
USING THE DVD / iPod
FEATURES
YUVSCART
adaptor
(applicable to
model L19LIDI9E
/ L19LIDI9WE
/ L22LIDI9E /
L22LIDI9WE only)
