DolbyDigitalisasoundsystemdevelopedbyDolbyLaboratoriesInc.Thisunitautomatically
recognizesDVDsthathavebeenrecordedwithDolbyDigital.
NotallDolbyDigitalsourcesarerecordedwith6channels.
SomesourcesmarkedDolbyDigitalmayberecordedinDolbySurround,a2channelsystem.
Lookforthislogoonyourunit.
ManufacturedunderlicensefromDolbyLaboratories.
‘Dolby’ and the double-D  symbol are trademarks of Dolby
Laboratories.
DOLBY DIGITAL (For DVD)
USING HEADPHONES
• Turn down the volume before connecting
headphonestotheunit,thenadjustthevolume
toyourdesiredlevel.
• Whenheadphonesareconnected,nosoundwill
comefromthefrontspeakers.
Note:
• Avoid listening tosound at high levels for
prolongedperiodsoftime.Thismaybeharmful
toyouandmaycausehearingloss.
Earphones / Headphones
(1/8”[3.5mm]diameterplug)
CONNECTING HDMI (applicable to model L19LIDI9E / L19LIDI9WE / L22LIDI9E
/ L22LIDI9WE only)
HDMI(HighDenitionMultimediaInterface)supportsbothvideoandaudioonasingle
digital connection for use with DVD players, DTV, set-top boxes and other digital AV
devices. HDMI was developed to provide the technologies of High Bandwidth Digital
ContentProtection(HDCP)aswellasDigitalVisual
Interface(DVI)inonespecication.HDCPisused
toprotectdigitalcontenttransmittedandreceived
byDVI-compliantorHDMI-compliantdisplays.
HDMI hasthe capability to support standard,
enhancedorhigh-denitionvideoplusstandardto
multi-channelsurround-soundaudio.HDMIfeature
includeuncompresseddigitalvideo,abandwidth
of up to 2.2 gigabytes per second (with HDTV
signals),oneconnector(insteadofseveralcables
andconnectors),andcommunicationbetweenthe
AVsourceandAVdevicessuchasDTVs.
HDMI,theHDMIlogo andHigh-Denition
Multimedia Interface are trademarks or registered
trademarksofHDMIlicensingLLC.
ConnecttheHDMIcable(notincluded)asshown.
Makesureyouconnectthecablefromtheequipment
(HDMI OUT)tothisunit(HDMI IN).
Tooperatetheconnecteddeviceandplaythesource,
rstpresstheFUNCTIONbuttontoselecttheHDMImode.
CONNECTIONS
ToHDMI
INjack
ToHDMIOUT
jack
