Logosol B751 - Page 16

16
7
8
M8x12
M8x20
M8
M8
M8
12 x
2 x
8 x
4 x
4 x
2 x
8400-005-0010
8400-005-0010
8400-005-0020
8200-005-0200
Assemble the rail sections with the log bed. Note that these must
only be fitted in the lower hole and tightened loosely.
Fit the inner end cap plates to the outer ones.
Note that the two shock absorbers must be
mounted in the upper corners.
