Logosol M7 Owner's Manual

What follows is a brief description of the M7
components to assist in identifying them during
assembly. A more complete listing is found at the end
of the manual.
1 Guide rail
2 Long leg
3 Horizontal beam
4 Short leg
5 Cross beam
6 Edge support
7 Log bed
8 Guide rail strut
9 Foot
10 Log rest
11 Knee joint
12 Carriage
13 Log grip
14 Lifting beam
15 Ratchet bar
16 Ratchet bar stop plate
17 Saddle plate
18 Ratchet Cam
Cam Axle
19 Ratchet handle
Ratchet neutral plate
Turning spring
20 Crank
Lockring
Lockring with line attachment
21 Plastic slide rail on log bed
Indicator
22 Angle fitting
23 Line pulleys
9
15
16
17
18
19
22
21
23
20
2
1
3
4
5
6
7
8
9
10
11
12
13
14
M7 WoodWorkers Mill components
