GENERAL PRESENTATION OF THE CRANKSET
Distinctive feature of the zed 3 crankset: The LOOK ZED 3 crankset is the rst AERO carbon
monobloccrankset.Thecranksandthestarchainringsupportaresecuredtotheaxleofthecranksetto
achieveasyetunequalledrigidity.Entirelymadeofhighstrengthcarbonbre,itisbothlightandstrong,
uidandaerodynamic.TheZED3isthefruitofnumerousyearsofresearch anddevelopmentand
includestwotechnologiespatentedbyLOOK:
1.ThevariationinthelengthofthecranksusingTRILOBEtechnology.Assuch,withacranksetyou
caneasilyselectfrom3speciccranklengthsforcycling,byturningtheoffsetscrewathirdofa
turnnowyourpedalaxle.Thisisaquickchangeanddoesnotrequireanyspecialtoolsandallows
youtocover:
•Size1crankset:155mm,157.5mmor160mm
•Size2crankset:162.5mm,165mmor167.5mm
•Size3crankset:170mm,172.5mmor175mm
2.Thepossibilitytottwodoublechainringswithaninter-axledistanceof130mmorcompactinter-
axledistanceof110mm.Thebranchesofthestarfeatureadoublesetoffasteningsthatmakeit
possibletoaccommodatethe2standardchainringsontheinteriorside.
EXPLODED VIEW
Fig 1
Locking
nut
Screw
M3x20
Bearing
6810
Expanding
ring
Framethatts
aZedbottombracket
Bearing
6810
Right
ring
Expanding
ring
Zed3crankset
equippedwithchainrings
