ASSEMBLING THE PEDALS
Fig 11
Adjusting the length of the cranks:
Positionthearrowonthesupportwasherfacingthedesiredlengthmarkerthenpositionthetrilobenut
ontheothersideinthesameposition.Screwthepedaltotherecommendedtorque.TheZED3crankset
iscompatiblewitheverypedalonthemarket.
Attention:
•Carefullycheckthepositionofthetrilobenutineachofthetwocranksbeforecyclinginordertobe
surethatyouhavepositionedtherightorleftcranksatthesamelengths.Iftherightandleftcranksare
differentlengthsthiscancauseseriousphysicalinjury.
•Therecommendedtorquesmustberespectedwhentighteningthepedals(20NmminimumforLOOK
pedals). Failure to respect the torques can cause damage to the product and, as a result, lead to
accidents,physicalinjuriesordeath.
•Degreaseandcleanthesurfaceofthenutthatisincontactwiththecrankbeforettingthepedals.
Dustand/oranyotherparticlesonthetrilobenutoronthecrankcoulddamagethecranksetorpedal.
•Therightnut(tobettedontherightcrank)isidentiedbytheletterR,andtheleftnut(tobettedon
theleftcrank)featurestheletterL.
Pedal
ZEDcrankset
Trilobenut
Trilobewasher
