Look ZED 3 - FITTING THE CHAINRINGS ON TO THE CRANKSET; FITTING THE CHAINRINGS

28
EN
FITTING THE CHAINRINGS ON TO THE CRANKSET
ItisrecommendedtottheLOOKZED3chainringswiththeZED3crankset.TheseLOOKZED3
chainringsaredevelopedtobecompatiblewiththedifferentgroupsandareoptimisedforweightgain,
gearshiftsandrigidity.
However,thereisattingskitforstandardchainringscontaining5screwsand5strutsandthedoubleor
compactchainringsthatmatchtheconstraintsdescribedbelowcanequiptheZED3crankset:
- contain5mountingholes
- haveaninter-axledistanceof110mmor130mm
- haveaneffectiveclampingwidthof4mmfortheexteriorchainring
- haveaperfectlyatexteriorsurfacefortheexteriorchainring
- haveaneffectiveclampingwidthof3.5mmfortheinteriorchainring
- accepttheplacementofthespecicLOOKinter-chainringstrutswithawidthof3.5mm
Foranyotherchainrings,suchasovalchainrings,pleaserefertothecompatibilitytableavailable
fromchainringsuppliersandonthewebsitewww.lookcycle.com.
Chainringmoun-
tingscrew(x5)
Interior
chainring
Inter-chainring
strut(x5)
Exterior
chainring
ZED 3
crankset
FITTING THE CHAINRINGS
Fig 2
