FITTING THE CHAINRINGS ON TO THE CRANKSET (cont.)
Fitting the chainrings on to the crankset:thechainringsmustonlybettedtotheZED3crankset
whenthecranksetisdetachedfromtheframe.
1.Startbydismantlingthecranksetbeforettingthechainrings(see§dismantlingtheZED).
2.BeforettinganychainringstotheZED3crankset,besuretocheckthatthechainringsupport
surfacesare clean, smooth andfree from anyelements that couldbecome lodged betweenthe
chainringandthecrankset.Thiscouldsignicantlyaffecthowatyourchainringsareandtherefore
howeffectiveyourgearchangesare.
Exterior
chainring
Ontheside
oftheframe
3.5mm
Interior
chainring
5mm
3.2mm
Exterior
chainring
Ontheside
oftheframe
3.5mm
Interior
chainring
4mm
3.5mm
ZEDstar
crankset
ZEDstar
crankset
LOOK ZED 3 CHAINRINGS
COMPATIBILITY OF STANDARD
CHAINRINGS
Fig 3 Fig 4
Chainringsupport
surfaces
