FITTING THE ADAPTORS
Fig 15
Positionthetwoadaptorasksintothebearing
seatsintheframethenscrewthe3xM5x60
screwstotherecommendedtorque(5Nm)in
ordertolockthewholeassembly.
ScrewFHCM5x60mm(x5)
Torque5Nm
Rightadaptor(threadingonthe
left1.37x24TPI)
Flaskpiercedwith3holestofor
thescrews.
Leftadaptor(threadingon
theright1.37x24TPI)
Non-piercedask.
FITTING THE ADAPTORS BSC REF DTCD / 0268992
Fitting the BSC adaptors:
Forcompatibilityreasons,aBSCthreadedbottombracketcanbettedtoaframecreatedforaZED
crankset.Todothis,thereareadaptorstobettedinsteadofthe6810bearingsasshowningure12.
Attention:
• This operation requires specic tools, it is essential that it is completed by a specialist Look
retailer.
• After tting the crankset and bearings, check that the interior bearing seats in the bottom
bracket of the frame are clear of any dust or other particles that could damage the adaptors.
• The M5x60mm screws must be tightened to the recommended torque: 5Nm.
