Look ZED 3 - REMOVING THE BEARINGS

40
EN
Hitthetoolwiththemallettoremovethebearing.
Removethedisassemblyringtoremovethemiddle.
Directlyslidethettedmiddleintotheframe,placingthedisassemblyringasasupportonthebearing.
Hitthetoolwiththemallettoremovethebearing.
Slidethedisassemblyringintothebrackettosupport
theinsideofthebearing.
-Usetheplanestopassthroughthe1stbearing.
-Placetheringbackinthebracket.
-Placetheringtosupportthebearing.
Liftthewholetoolontothedisassemblyring.
REMOVING THE BEARINGS
[ C ]
[ D ]
[ A ]
[ B ]
Fig 14
Specicassem-
blytool
Specictool
explodedview
Disassembly
ring
Dismantling the 1st bearing
Dismantling the 1st bearing
