Basic Setup4
3. Secure the bracket to the mounting surface with the included mounting screws (×4). Make sure
all screws are fastened tightly using the included screwdriver (item A+B in toolkit).
NOTE
• Insert the included drywall anchors if you are mounting the camera onto drywall.
• The hole at the top of the mounting bracket will be used in step 5, once the camera is attached to the
mounting plate.
4. Lower the camera base onto the mounting bracket so the 2 tabs in the mounting bracket lock
into the 2 slots in the camera base.
LWB4800 / LWB4900 Series LWB5800 / LWB6800 Series
#LX400109; r. 5.0/56381/56402; en-US 11
