Using the Main Menu15
Note
In order to enable Snapshot recording, the following menu options must be configured:
• The Snapshot schedule must be enabled for times that you would like to save snapshots. See
15.3.17 Configuring the Snapshot Schedule, page 67.
• Snapshot recording must be enabled for motion detection in the Event menu. See 15.3.8 Configuring
Motion Detection, page 59.
To configure snapshot recording settings:
1. From the Main Menu, click
and select Recording>Snapshot.
2. Under Snap Number, select the number of snapshots the system will take when the
snapshot button is pressed.
3. Configure the following settings for snapshots saved automatically from motion detec-
tion or the snapshot schedule:
• Channel: Select the channel you would like to configure.
• Mode: Select Timing for the system to take snapshots according to the snapshot
schedule (see 15.3.17 Configuring the Snapshot Schedule, page 67) Select Trig-
ger for the system to take snapshots only when triggered by motion detection
(snapshot must be enabled in the Motion Detect menu; see 15.3.8 Configuring Mo-
tion Detection, page 59).
• Image Size: The image size is the same as the Main Stream resolution of the
camera.
• Image Quality: Select the snapshot image quality between 1 (lowest) and 6
(highest)
• Snapshot Frequency: Select the number of snapshots (up to 6) the system will
take each time.
4. Click OK to save changes.
15.1.8 Creating Custom Channel Names
You can assign custom names to your cameras. For example, you can name your cameras
based on their location (e.g. hallway or front door).
To create custom channel names:
1. From the Main Menu, click
and select Channel Name.
#LX400021; r. 1.0/16017/16020; en-US
47
