LNR400 Series System
Specifications
23
23.1 System
Operating System
Embedded LINUX
Pentaplex
Simultaneous View, Record, Playback, Backup,
and Remote Monitoring
Number of Channels 8/16 Channels
23.2 Inputs/Outputs
Video IN 8/16 ch: 8 PoE Video Input
Video OUT No
VGA OUT Yes
HDMI Yes
Audio IN
1 Line IN (RCA) for service only
Audio OUT 1 Line OUT (RCA) for service only
USB Port 1 at the back, 1 at the front
Alarm IN 8 Alarm IN
Alarm OUT 3 Alarm OUT
Video Output Resolution
1920×1080, 1280×1024, 1280×720, 1024×768
PTZ Control Lorex IP PTZ cameras only
23.3 Display
Display Split 8 ch: 1/4/8/9
16 ch: 1/4/8/9/16
Live Display Speed 8 ch: 240FPS NTSC, 200 PAL
16 ch: 480FPS NTSC, 400 PAL
OSD Camera Title, Time, Camera Lock, Motion Detec-
tion, Recording Status
System Navigation USB mouse, IR remote control, front panel buttons
Motion Area Setting Adjustable grid (22x18)
Sensitivity Levels
100
Firmware Upgrade Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization Auto time sync by NTP server
23.4 Recording
Compression H.264
Resolution
1080P (1920×1080) / 720P (1280×720)
#LX400021; r. 1.0/16017/16020; en-US
176
