Installing the Receiver
4
3. Connect the included power adapter to the receiver and to an electrical
outlet.
4. Charge the receiver overnight before using for the first time.
5. Pull up the antenna on the back of the LCD receiver.
6. Press and hold the power button on the front panel for 2 seconds. The
startup screen appears, followed by live video from your camera(s).
NOTE
If one or more cameras do not appear when selected (for example, Camera 2 is
plugged in but does not appear on channel 2), see 11 Pairing Additional Cameras,
page 53.
Tips:
• Place the receiver in a location that will have a clear reception to your cam-
era. Try to maintain line-of-sight and minimize the number of obstructions
between the camera and receiver.
#LX400030; r. 2.0/22135/22135; en-US
