Using the System
7
5. Battery indicator: Shows remaining battery life. The icon flashes on and
off when battery is critically low to indicate that the receiver should be
plugged into a power outlet right away.
6. Date & time stamp: The current date and time on the system.
7. Recording indicator: A red circle appears in the bottom right-hand cor-
ner of the screen when recording is in progress.
8. Volume indicator: Shows the current volume of the receiver. The volume
indicator appears on screen when you change the volume using the
/
keys.
7.2 Navigating Menu Screen
Use the system menus to configure settings.
• Press to open the Main Menu.
• Press the
keys to move the cursor left, right, up, and down.
• Press
to open sub-menus and confirm menu selections.
• Press
to go back or exit out of menus.
7.3 Viewing Modes
There are 3 different viewing modes available on the system: Single Channel
Viewing mode, Auto Sequence Viewing mode (view individual channels
automatically in sequence), and Quad Viewing mode (view all 4 channels at
once in split-screen).
To change viewing modes:
• Press
/ to select between channels 1–4 in single channel view, as
well as to enable Quad and Auto Sequence Viewing modes.
7.3.1 Auto Sequence Viewing Mode
By default, Auto Sequence Viewing mode cycles through all connected chan-
nels in full-screen. If you wish to view only 2 or 3 cameras in each cycle, you
#LX400030; r. 2.0/22135/22135; en-US
