4 Installation
5. Pull the connection cable(s) through the mounting surface and
wall mount.
6. Attach the included flat washers (4x) to the included mounting
screws (4x).
7. Firmly attach the wall mount to the mounting surface using the in-
cluded mounting screws (4x) and flat washers (4x).
NOTE
Imagery for illustration purposes only.
WARNING
Make sure to install the wall mount bracket in a location that
can support the camera’s weight. If mounting the camera on a
drywall surface, you must drill at least 2 of the mounting
screws through a wooden stud to ensure a stable mount. See
the diagram below for details.
#; r. 4.0/47037/47040; en-US 15
