6 Controlling the PTZ camera with LNR / NR Series NVRs
• Under No., select the number of the tour you would like to go to
and click
.
NOTE
• There is a 5 second minimum pause between presets.
• Tour panning / tilting speed is slower than manual panning / tilt-
ing speed. The reduced speed maximizes reliability.
• We recommend you do not make the camera pan more than
270° between any two points in a tour.
6.2.3 Pattern
Patterns automatically cycle the camera between two positions.
To create a pattern:
1. Click
to open the PAN/TILT/ZOOM menu.
2. Click the Pattern tab.
3. Under Pattern, enter the pattern you would like to configure.
4. Move the camera into the desired start position and click Start.
5. Move the camera into the desired end position and click End.
6. Right-click to return to the advanced PTZ controls window.
#; r. 4.0/47037/47040; en-US 25
