Lovibond EC 2000 Gardner - Power- USB; Power- Battery

6
Keypad:
Display Icons:
Power- USB:
Power- Battery:
Icon
Function
Battery Low
Powered by Battery
Powered by USB
SD Card OK
Warning
Test
Zero
Power
The USB port can be accessed
by sliding the panel at the rear
of the instrument.
The batteries can be replaced
by removing the 4 x screws at
the back of the instrument and
removing the battery cover.
Ensure the cable connector is inserted
into the socket in the correct
orientation. The symbol on the USB
connector should be facing down.
Top of Connector
Top of Instrument
