Navigating
Ú
Note: Navigating is not available on 4x Sonar only models.
The navigation function is available on the GPS page.
The navigation function included in the system allows you to
navigate to the cursor position, to a waypoint, or along a predefined
route.
For information about positioning waypoints and creating routes,
refer to "Waypoints, Routes, and Trails" on page 18.
When you select to navigate to the cursor position, to a waypoint or
a predefined route, the Navigation option appears in the menu.
Select Navigate to access cancel, restart, and skip a routepoint
options.
Navigate to cursor position
You can start navigating to a cursor position on the GPS plotter or
sonar panel.
Position the cursor at the selected destination on the panel, and
then select the Goto Cursor option in the menu.
Ú
Note: The Goto Cursor menu option is not available if you are
already navigating.
Navigate to a waypoint
You can start navigating towards a waypoint on the panel. Position
the cursor over the waypoint, select the waypoint in the menu and
then the Goto waypoint option in the menu.
Navigate a route
You can navigate a route on the image by positioning the cursor
over the route, selecting the route in the menu and then the start
route option in the menu.
When route navigation is started, select the Navigation menu
option for canceling the navigation, skipping a waypoint, and
restarting the route from current vessel position.
5
Navigating | Hook² X Series Operator Manual
