Lowrance HOOK2-4x User Manual

Application pages
1
3
2
4
5
1 Application panel
2 Menu - Panel specific menu.
3 System Controls dialog - Quick access to basic system
settings.
4 Dialog - Information to or input from the user.
5 Alarm message - Displayed if dangerous situations or
system faults occur.
Each application connected to the system is presented on panels.
Introduction | Hook² X Series Operator Manual

Lowrance HOOK2-4x Specifications

General

Display Size	4.3 inches
Display Resolution	480 x 272 pixels
Display Type	Color TFT
Sonar Frequency	200 kHz
Power Output	200W RMS
GPS	No
Waterproof Rating	IPX7
Sonar Type	Broadband
Transducer	Bullet Skimmer
Mounting Type	Bracket
Maximum Depth	500 ft (152 m)
