Lowrance HOOK2-4x User Manual

DownScan
Ú
Note: DownScan is available on 5x and 7x models only.
DownScan provides detailed images of structure and fish directly
below your boat, down to 91 m (300 ft) at 455 kHz and 46 m (150 ft)
at 800 kHz.
The DownScan image
2
1
1 Data overlay
2 Range limit
Zooming the DownScan image
You can zoom a DownScan image by using the Zoom keys.
Customize the image settings
By default the unit is set to Auto mode, and most settings are
automated. It is recommended that only experienced sonar users
use the customize settings to further customize the sonar image.
Select Auto in the menu and change to custom mode to customize
image settings.
8
DownScan | Hook² X Series Operator Manual

Lowrance HOOK2-4x Specifications

General

Display Size	4.3 inches
Display Resolution	480 x 272 pixels
Display Type	Color TFT
Sonar Frequency	200 kHz
Power Output	200W RMS
GPS	No
Waterproof Rating	IPX7
Sonar Type	Broadband
Transducer	Bullet Skimmer
Mounting Type	Bracket
Maximum Depth	500 ft (152 m)
