Jackplate mount supplies (not included)
6 mm (1/4”) Drill bit (Jackplate
Mount)
M6 (1/4”) jackplate mount bolts
Warning: Before installing the transducer on the
jackplate, lower the jackplate to its lowest setting to
make sure there is enough clearance between the
jackplate, engine, transom, and the transducer. Lack of
clearance could damage the transducer when the
engine is all the way down.
To mount transducer on jackplate using transom bracket:
1. Choose a transducer location on the inside or outside of the
jackplate.
2. Adjust the jackplate up and down to make sure the transducer
will not obstruct jackplate movement.
3. Make sure nothing blocks the sonar beam on either side of the
transducer.
4. Route the transducer cables through the bracket to the location
where the module will be installed.
5. Move the transducer bracket into the desired position and use a
pencil to mark the holes through the hinge hole and hole in the
side of the bracket.
6. Using a 6mm or equivalent drill bit, drill the holes into the
jackplate.
7. Slide the bracket inside the jackplate and align the bracket holes
with holes you drilled in the jackplate.
8. Slide M6 bolts with washers into each hole on the side of
jackplate.
9. Guide the bolts through the Transducer mounting bracket
holes.
10. Place a washer over the end of the bolts and tighten the nuts.
11. Connect the transducer cables to the module ports.
After the transducer is connected and your boat is in the water, turn
on the Flip Left/Right feature in your display unit to ensure what is
shown on the left and right side on your display corresponds with
what is on the left and right side of your boat. Refer to your display
unit's Operation manual for more information.
Installation | StructureScan 3D Transducer
11
