Lowrance StructureScan 3D Installation Manual

Parts and accessories
The most up-to-date parts and accessories are available at:
simrad-yachting.com or lowrance.com.
StructureScan 3D Transducer (000-12396-001)
Includes transducer, transom mounting bracket, and assembly and
mounting screws, washers, and nuts.
StructureScan 3D, StructureScan HD & TotalScan Skimmer
Transom mount kit (000-12603-001)
Includes transom mounting bracket, and bracket assembly and
mounting screws, washers, and nuts.
StructureScan 3D & TotalScan Skimmer Flush mount kit
(000-12602-001)
Includes 2 piece Flush mount mounting bracket. Use assembly and
mounting hardware supplied with the transducer.
10-FT 12-PIN Transducer Extension cable (000-12752-001)
5
16
Parts and accessories | StructureScan 3D Transducer

Lowrance StructureScan 3D Specifications

General

Frequency	455 kHz, 800 kHz
Beam Width	60° at 455 kHz, 45° at 800 kHz
Transducer Type	Skimmer
Mounting Options	Transom mount
Max Depth	300 ft (91 m)
Connector	9 Pin
Cable Length	20 feet
Maximum Range Side	600 feet
Depth Capability	300 ft (91 m)
Compatibility	HDS Gen3, HDS Carbon, HDS LIVE
