L-STAT User Manual 11 LOYTEC
Version 1.0 LOYTEC electronics GmbH
Segment
Name
Description
Direct
Access
wind
Wind alarm symbol

rain
Rain alarm symbol

window
Window open alarm symbol

fan
Fan symbol

valve
Valve symbol

logo
Loytec logo symbol

green_leaf_3
The green leaf symbols can be used to
display the level of eco-friendliness or
to visualize environmental conditions.

green_leaf_2

green_leaf_1

green_leaf_0

bar_left_2
The left bar graph symbols can be used to
display a heating or cooling stage in
automatic or manual mode.

bar_left_1

bar_left_0

manual_left

auto_left

bar_right_2
The right bar graph symbols can be used
to display a fan stage or valve position in
automatic or manual mode.

bar_right_1

bar_right_0

manual_right

auto_right

