Register Name
Register
Address
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
display_value_0
64
0x0040
[0x0000]
display_value_1
65
0x0041
[0x0000]
display_value_2
66
0x0042
[0x0000]
display_value_3
67
0x0043
[0x0000]
display_value_4
68
0x0044
[0x0000]
display_value_5
69
0x0045
[0x0000]
display_value_6
70
0x0046
[0x0000]
display_value_7
71
0x0047
[0x0000]
display_value_8
72
0x0048
[0x0000]
display_value_9
73
0x0049
[0x0000]
display_value_10
74
0x004A
[0x0000]
display_value_11
75
0x004B
[0x0000]
display_value_12
76
0x004C
[0x0000]
display_value_13
77
0x004D
[0x0000]
display_value_14
78
0x004E
[0x0000]
display_value_15
79
0x004F
[0x0000]
 The DSSA or DSEU bit at the corresponding display value configuration at address
256 to 286 has to be cleared to display the content of a display value register (see
Table 28 on Page 39). If the DSSA or DSEU bit is cleared this specifies that a display
value is used instead of a sensor value. The semantic meaning specifies which text is
displayed along with the specific display value. For an overview on this topic please
see Figure 6 on Page 21.
 All registers are 16 Bit signed values. Depending on the modbus_unit specified with
the corresponding display value configuration register at address 256 to 287 (Table 28
at Page 39) the value needs to be scaled as described in Table 39 at Page 51 to achieve
the desired result.
Table 11: Display Values
