(4) Tachometer and Hour meter
Tachometer shows the engine revolutions per
minute.
The number 0005.3 in Hour meter shows that the
tractor has been used for 5.3hours
(5hours and 18minutes).
(5) Engine coolant temperature
gauge
This gauge indicates the temperature of coolant
The closer the needle approaches “H”, the higher
the temperature of engine coolant is.
Warning
▶
The radiator is very hot. When opening the radiator cap, It may cause a danger of a
burn due to the escape of hot coolant or steam.
▶
After the coolant is cooled down sufficiently, open the radiator cap with protective
gloves and clothing.
▶
If the needle of engine coolant temperature gauge indicates red zone,
- Stop the engine immediately and check the coolant level after engine cools down.
If necessary, add coolant.
- Clean the radiator screen if dry grass etc. are attached.
- If the trouble is repeated, contact your authorized dealer for check.
Caution
3
3 3
3 - 2
(6) Fuel level gauge
This gauge indicates the remaining amount of fuel.
If the needle indicates “E”, fill the fuel tank
immediately.
Fuel level
gauge
