(11) Driver’s seat (HST type)
 At the lower end of the seat, there is a switch to
detect that operator is sitting in seat.
 If the operator gets up from the seat while engine
is running, the engine will stop automatically for
safety in case of ;
- getting up from the seat for more than 2 seconds
with HST pedal NOT in neutral position.
- the HST pedal is in NEUTRAL and rear PTO is
engaged without applying the parking brake.
USA version (HST)
European version (HST)
(12) Seat adjustment
Before operating the tractor, adjust the driver’s seat
position according to body size and length.
warning
▶ DO NOT arbitrarily remove the seat switch. If it is necessary to replace the seat the
seat switch has to be replaced together. If not, the engine does not start.
- the PTO select lever is on “MID” or “REAR/MID”
position.
 Before leaving the driver’s seat, turn the PTO
switch “OFF” and place the PTO select lever on
“REAR” position, and apply the parking brake.
European version (HST)
3
3 3
3 - 12
warning
▶ DO NOT put your hand under the seat while sitting. It may cause a serious injury
by seat suspension.
position according to body size and length.
1) After sitting on driver’s seat, move the seat
adjustment lever upward or left side to release the
lock.
2) Move the driver’s seat forward or backward
depending on driver’s body length.
3) Release the seat adjustment lever and check the
seat is locked.
Adjust the seat suspension to fit the weight of
operator (if fitted).
Seat adjustment lever
