(7) Differential lock pedal
If the tractor cannot go forward as one side rear
wheels are slipping, press the differential lock
pedal.
Differential lock is effective for working on slippery
ground and working with a plough.
If engaged, both rear wheels will rotate at equal
speed. So, It disturbs steering operation and you
cannot turn.
Differential lock
pedal
HST type
Take your foot off the pedal to release the differential lock. If the traction is equalized, the differential
lock is released automatically.
If the differential lock does not disengaged, depress one side brake
▶
Do not turn the tractor while the differential lock is engaged.
▶
Do not use the differential lock while driving on the road.
▶
Stop or slow the tractor before engaging the differential lock.
Warning
(8) HST forward/ reverse pedal
(HST type)
Press HST pedal forward to drive the tractor
forward.
Remove foot from the pedal to stop the tractor.
As the pedal returns to neutral, the tractor will be
stopped.
If the differential lock does not disengaged, depress one side brake
pedal slightly for a second, and then the other.
Reverse
Forward
3
3 3
3 - 10
The tractor speed is depending on the HST pedal
stroke.
The reverse operation as the same as the
forward.
warning
▶
Press the brake pedal to stop the tractor at high speed.
Because even if the HST pedal becomes to be neutral, it takes long distance to
stop the tractor at high speed.
▶
Do not suddenly press the HST pedal to avoid the impact of starting.
