Appendix 4 Instruction List
App. 4-15
(4) Comparison instruction (continued)
32 Bits
Data
Group
Compare
(LOAD)
Compares (S1), (S1+1), …,
(S1+N) to (S2), (S2+1), … ,
(S2+N) 1 to 1, and then saves
1 in Bit Result(BR) if each
value compared meets given
condition
32 Bits
Data
Group
Compare
(AND)
Performs AND operation of
(S1), (S1+1), …, (S1+N) &
(S2), (S2+1), … , (S2+N) 1 to
1 Compare Result and Bit
Result(BR), and then saves its
result in BR
32 Bits
Data
Group
Compare
(OR)
Performs OR operation of
(S1), (S1+1), …, (S1+N) &
(S2), (S2+1), … , (S2+N) 1 to
1 Compare Result and Bit
Result(BR), and then saves its
result in BR
To Next Page
